IRON WILL RIP TKO ELITE V1 ARROW BUILD
EASTON AXIS ARROW BUILD
Arrow Components
Precision Machine Built
To provide the most accurate and consistent arrow build possible, we developed a machine to precisely cut and square both ends of the arrow and install our HIT inserts. This never-before-seen precision assures consistent force through the nock at the arrow launch and very accurate alignment from nock to shaft to point for the most accurate flight.
Nocks
For the most precise arrows, we add AAE IP Nocks standard to our custom cut arrows for exceptional consistency and great string reaction. These nocks connect the arrow shaft closer to the string than traditional nocks, which results in a more precise and repeatable arrow send-off.
Arrow Length
To find your minimum arrow length, mark your arrow in front of your rest at full draw and then add 0.7 inch for 10 grain and 1.0 inch for 25 grain Impact Collars to make sure the Impact Collar doesn't contact your rest.
Our machine cut arrow lengths are measured from carbon to carbon, and don't include the point length or nock length.
HIT Inserts
Our machine is engineered to build arrows with Iron Will HIT Inserts, so your broadheads align with your arrow's inner diameter for the most accurate flight.
Impact Collars
Designed to be built with Iron Will Impact Collars for a stronger arrow connection and extra front-of-center (FOC) weight options.
Flight Optimized Field Points
Iron Will Field Points are design-optimized using fluid dynamic modeling to match broadhead flight characteristics more closely than ordinary field points.
Precision Fletched
VANES
For ideal arrow and broadhead flight, we precision fletch every Easton Axis arrow with three 3° right helical Iron Will Hybrid Hunter vanes. Iron Will RIP TKO Elite V1 Arrows are hand fletched with precision jigs set to 2.25° right helical, which we have found to be optimal with their three Iron Will 2.5 Vanes.
Both of these vanes were developed through extensive computational fluid dynamic modeling as well as emperical testing to provide the best arrow flight with broadheads.
12 Arrow
Travel Case
Lightweight and compact — to ensure your arrows make it from home to the field. Whether you're heading in deep on horseback, navigating airport handling, or simply placing them in the back of the pickup, your hunt is too important to risk breaking arrows on the way there. Designed to hold 12 arrows so you can hunt hard and with confidence knowing you've got backups at-the-ready if the unexpected happens.
This travel case is automatically included with custom cut 12 packs.
“When it comes to reliable arrow flight, Iron Will broadhead and component tolerances go a long way towards ensuring the most accurate flight and deepest penetration possible. Through our new machine built arrow process, we can mitigate arrow build inconsistencies like never before. Couple this with a vane configuration scientifically proven to provide great accuracy and stability and the result is the most repeatable and reliable arrow build for bowhunters.”
— Bill Vanderheyden, Owner and Lead Engineer
